Sectional Model 2432

Duty Rating: Heavy-Duty
Insulation/R-Value: 9.4
Layers: 3
Warranty: 10-Year
Price: $$$

download brochure

Description

Sectional Model 2432

Solid steel construction is the basis for the Model 2432. Two tough steel skins surround 2 inches of CFC-free polystyrene insulation. In addition, a thermal break creates a barrier to keep heat and cold from transferring through the door.

STRENGTH INSULATION
24 gauge exterior and 27 gauge interior steel bonds to rigid polystyrene to create a strong, energy efficient panel.

ECO-FRIENDLY
Amarr’s polystyrene insulation is free of Ozone depleting Chlorofluorocarbons (CFC) while providing efficient insulation to help reduce the negative environmental impact of heating and cooling energy use.

Section Profile

  • Ribbed Stucco

Ribbed Stucco

Construction

  • Triple-Layer Steel Insulation Steel

Commercial Steel Triple Layer Construction

Windows

Commercial Window 24x12 Insulated

24″x12″ Insulated

24″ x 6″ Insulated

Available Colors

  • True White
  • Sandtone
  • Commercial Brown
  • Commercial Gray

Specifications

R-VALUE 9.4
STEEL THICKNESS 24/27 Ga.
PANEL DESIGN Pencil Groove
STEEL EMBOSSMENT Stucco
CONSTRUCTION LAYERS Three
MAX STD WIDTH 24’2″
MAX STD HEIGHT 26’1″
DOOR THICKNESS 2″ (5.1cm)
