Sectional Model 2042

Duty Rating: Extra Heavy-Duty
Insulation/R-Value: 19.4
Layers: 3
Warranty: 10-Year
Price: $$$

download brochure

Description

Sectional Model 2042

This Extra Heavy-Duty top-of-the-line high R-value door is constructed using 20-Gauge exterior steel that is foamed-in-place with polyurethane insulation which creates a strong monolithic panel that is energy efficient.

Maximum R-value
Our polyurethane insulation provides the best R-Values per inch when compared to other common types of sectional door insulation.

Security Strength
20-gauge steel exterior skin with the added strength of foamed-in-place polyurethane insulation provide maximum strength and security for your opening

Section Profile

  • Flush Stucco

Construction

Commercial Steel Triple Layer Construction

  • Steel Insulation Steel

Track: All Amarr Doors are available with both
2″ or 3″ track in Standard Lift, High Lift, Vertical Lift,
Low Headroom, and Follow the Roof Pitch. Custom track configurations are also available. For drawings and more information, please visit our downloads website.

Hardware: Amarr hardware includes minimum
14-gauge galvanized steel hinges and 13-gauge galvanized steel track brackets. All rollers have
minimum 10-ball bearings.

Springs: Torsion springs are oil tempered, helical wound and custom computed for each door for a minimum 10,000 cycle life. Optional springs are available up to 100,000 cycle life.

Windows



Commercial Window 24x12 Insulated

24″x12″ Insulated

26” x 13” insulated

24″ x 6″ Insulated

Commercial Window Full View

Full View

Perforated Aluminum Full View

Available Colors

  • True White

Specifications

R-VALUE 19.4
STEEL THICKNESS 20/27 Ga.
PANEL DESIGN Flush
STEEL EMBOSSMENT Stucco
CONSTRUCTION LAYERS Three
MAX STD WIDTH 40’2″
MAX STD HEIGHT 26’1″
DOOR THICKNESS 2″ (5.1cm)
